Category: Window Walls

YWE 60 T is a thermally improved 6-inch window wall system designed and engineered to meet the design challenges of today’s new buildings. The system is capable of spanning from floor to floor, even at higher design loads.

Snap-on face covers enable separate interior/exterior finishes for aesthetic and/or economic reasons. The system is glazed from the interior to reduce field labor with options for outside re-glazing. Optional head and sill anchors allow ease of installation for punched openings. Two sided structural silicone glazing at vertical mullions is also available as an option.

Read More

Product Data

Features

Thermally Improved

Benefits

  • 2-1/4” Face by 6” Overall Depth
  • Interior Glazed
  • Screw Spline or Shear Clip Construction
  • Two Piece Interior Glass Stop to Improve Performance
  • Optional Structural Silicone Glazed Intermediate Verticals
  • Separate Interior/Exterior Finish Options

Data

Construction Use: New

Sightline: 2-1/4"

Mullion Depth: 6"

Framing Installation Method: Continuous Head and Sill / Vertical Through / Screw Spline

Glazing Installation: Inside

Glass Type: Monolithic / Insulating

Glass Configuration: Front

Product Line

Anodized Plus® / MegaTherm®
