Category: Curtain Walls

The YUW 750 TU is a unitized wall system that can be captured or silicone glazed, designed to be assembled and glazed in a climate controlled environment for increased quality assurance of critical seals.

The YUW 750 TU is a unitized wall system designed to be assembled and glazed in a climate controlled environment for increased quality assurance of critical seals. Complete units are then shipped directly to the jobsite permitting rapid installation and dry-in of low to mid-rise commercial buildings.  The YUW 750 TU also easily interfaces with sun shades for a greater sustainable design solution.

Read More

Product Data

Features

Unitized/Shop-Glazed / Thermally Broken

Benefits

  • Versatile Framing Design
    • Captured:  2 1/2” sightline
    • 4-side structural silicone glazing
  • Advanced Thermal Barrier minimizes Heat Transfer
    • Improved Occupant Comfort
    • Increased Condensation Resistance
  • 90° inside and outside corners
  • 3-way adjustable curtain wall anchors
  • Simplified fabrication, assembly, and installation
  • Simplified dimensions for frame and glass lites for ease of installation and and an even aesthetic look
  • Dual Finish capability for captured version (inside / outside finish)

Data

Construction Use: New

Sightline: 2-1/2"

Mullion Depth: 7-1/2"

Framing Installation Method: Screw Spline / Unitized

Glazing Installation: Outside / Structural

Glass Type: Monolithic / Insulating

Glass Configuration: Front

Thermal Method: Pour and Debridge

Product Line

Thermabond Plus®
