Category: Window Walls

The YHW 60 TU is a thermally broken, unitized, hurricane impact-resistant system that builds on YKK AP’s line of versatile wall solutions for mixed use buildings.

The YHW 60 TU is a thermally broken hurricane impact- resistant system that builds on YKK AP’s line of versatile wall solutions for mixed use buildings. The glass plane is set to the front to maximize thermal performance and accommodates up to 1-5/16” glazing infill. Fast, efficient installation is achieved by using the same system for impact glazing on lower floors and the non-impact glazing on upper levels. Screw spline assembly and two piece mullions facilitate pre-glazing or inside glazing at the jobsite.

Read More

Product Data

Features

Unitized/Shop-Glazed / Thermally Broken / Hurricane Mitigation

Benefits

  • Slab edge cover to mimic the appearance of a curtain wall application
  • Tested for hurricane WZ3 & HVHZ – Large & Small Missile
  • Design Pressures up to 90 psf
  • 10’ Span; 5’ Spacing
  • Patented ThermaBond Plus® thermal break
  • 90º and 135º corners
  • Expansion, HD Mullions
  • Compatible with YKK AP entrances, terrace doors and zero sightline vents
  • High Performance Sill Flashing
    • No Blind Seals
    • Tall back leg for enhanced water resistance
    • Patented 3 point attachment of end dam

Data

Construction Use: New / Retrofit

Sightline: 2.5"

Mullion Depth: 6"

Framing Installation Method: Slab Edge / Screw Spline

Glazing Installation: Inside

Glass Type: Monolithic / Insulating

Glass Configuration: Front

Thermal Method: Pour and Debridge

Product Line

Anodized Plus® / ProTek® / Thermabond Plus®
